Branson 400 Series Welder
- 20kHz, 400, 700, 900, 1200 Watt
- 117VAC or 240VAC
- 402 Converter, 1/2-20 stud
- Typically 3/8-24 Stud for horn
- Time welding
- More Specs
- Download 400 Series Manual
Branson 5170 Welder
- 20kHz, 1700, 3200 Watt
- 240VAC
- 502 Converter, 1/2-20 stud
- Horns typically 3/8-24 or 1/2-20
- Time welding
- More Specs
- Download Branson 5170 Manual
Branson 8400 Welder
- 20 kHz, 450, 900, 1400, 1500, 1800 Watt
- Model: 8200, 8400, 8600, 8700, and 8800
- 402, 802, 803 Converter, 1/2-20 stud
- Horn is Typically 3/8-24
- Time welding
- 8400 Data Sheet
- Download Branson 8400 Manual
Branson 910IW or 920IW Welder
- 20kHz, 910IW (1000 Watt), 920IW (2000 watt)
- 910IW is 902J Converter, 920IW is 922JA Converter, 1/2-20 stud
- Typically 1/2-20 Stud for horn
- Time only
- Download 900IW Data Sheet
- Download 900IW Manual
Branson 910IW+ or 920IW+ Welder
- 20kHz, 1000 & 2000 watt
- 910IW+ and 920IW+
- 910IW+ uses 902J Converter, 920IW+ uses 922JA Converter, 1/2-20 stud
- Typically 1/2-20 Stud for horn
- Time and Distance Welding
- Download 900 IW+ Data Sheet
- Download 900 IW+ Manual
Branson 900 AE Welder
- 20 kHz, 500, 1000 & 2000 Watt
- Model: 900 Series
- 901AE uses 902J Converter, 921AE uses 922JA Converter
- Horn is usually 1/2-20 stud
- Time & Energy
- Usually coupled with a 900D or a 900M power supply
- Download Data 900AE Sheet
Branson 2000IW Series Welder
- 20kHz, 2000IW (1100 & 2200 Watt)
- 2000IW uses a CJ20 Converter, 1/2-20 stud
- Typically 1/2-20 Stud for horn
- Time only
- 2000IW Data Sheet
- Download 2000IW Manual
Branson 20000IW+ Welder
- 20kHz, 2000IW+ (1100 & 2200 Watt)
- 2000IW uses a CJ20 Converter, 1/2-20 stud
- Typically 1/2-20 Stud for horn
- Time and Distance Welding
- 2000IW+ Data Sheet
- Download 2000IW+ Manual
Branson 900 AES Thruster
- 20 kHz, 500, 1000 & 2000 Watt
- Model: 900 Series, Usually coupled 900M or MA power supply
- 901AES uses 902J Converter, 921AES uses 922JA Converter, 1/2-20 stud
- Time & Energy, and Distance
- 900AES Data Sheet
- Download 900AES / AOS Thruster Manual
Branson 910IW+ Rotary
- 20kHz, 910IW (1000 Watt) Rotary
- 910IW Converter 902J, 1/2-20 stud
- Typically 1/2-20 Stud for horn
- Time and Distance
- Setup for 2 position currently
- Download Series 30 Data Sheet
Branson 2000Xdt 30kHz Welder
- 30kHz, 2000xdt (1500 Watt)
- Uses a CJ20 Converter, 1/2-20 stud
- Typically 1/2-20 Stud for horn
- Time, energy, and Distance Welding
- Download 2000xdt Data Sheet
Branson 2000Xea Welder
- 20 kHz, 2500 Watt
- Uses CJ20 Converter, 1/2-20 stud
- Typically 1/2-20 Stud for horn
- Time and Energy
- Download 2000xea Data Sheet
Branson 3300 Watt Panel Power Supplies
- 20kHz, 3300 watt
- Uses CJ20 Converter, 1/2-20 stud
- Typically 1/2-20 Stud for horn
- Download 20:3.3 Panel PS Data Sheet
Branson 2000aed Welder
- 20kHz, 1100 Watt
- Uses CJ20 Converter, 1/2-20 stud
- Typically 1/2-20 Stud for horn
- Time, Energy, and Distance Welding
- Download 2000aed Data Sheet
- Download 2000d Power Supply Manual
Branson 900BCA Power Supply
- 20 kHz, 500, 1000 & 2000 Watt
- Model: 900 Series
- 910BCA uses 902J Converter, 920BCA uses 922JA Converter, 1/2-20 stud
- Timed by external system
- Download 900BCA Power Supply Manual
Branson 2000xdt, 15kHz 3300 Watt Power Supply
- 15kHz, 3300 watt
- Uses CJ15 Converter, 1/2-20 stud
- Typically 1/2-20 Stud for horn
- Download Branson 2000xdt Data Sheet
- Download Branson 2000X Manual
Coming Soon
- Branson something or other 🙂
Branson 900M Power Supply
- 20 kHz, 500, 1000 & 2000 Watt
- Model: 900 Series
- 910M uses 902J Converter, 920M uses 922JA Converter, 1/2-20 stud
- Download 900M Manual
